*FINE WPL 10 Series ï LED Weatherproof Lights ï IP65*

*Tough Light for Tough Places ï Dustproof, Waterproof, Worry-proof*

FINE WPL 10 Series is an industrial-grade batten light designed for places where normal LED battens fail ï basements, tunnels, utility corridors, car parks, factories. As shown in the long utility tunnel image, continuous WPL lights give bright, uniform, 120 wide light on pipes and floor, with full dust and moisture protection ï working 24/7 where cleaning is never done.

*Technical Specifications*

- *Model WPL 10 Series ï LED Weatherproof Lights

- *Power Options

- 20W (2 Feet) ï 2200 Lumens ï For small passages, lift pits, meter rooms

- 40W (4 Feet) ï 4400 Lumens ï For long tunnels, parking, factories ï *As shown in image ï Best Seller*

- *LED Colors

- 3000K Warm White ï For residential basement, warm look

- 4000K Neutral White ï True natural ï Most selling for industrial

- 6000K Cool White ï Maximum brightness ï As in tunnel image

- *Body Polycarbonate Body ï Full PC housing + PC diffuser ï Unbreakable, non-corrosive ï No yellowing

- *Protection IP65 Dustproof & Waterproof ï Full protection from dust, water jet, humidity ï As needed in tunnel with pipes

- *Light Angle 120 Wide Beam ï One light covers full width of corridor as in image

- *Driver In-built High PF Isolated Driver, 100V-285V AC, Surge 4kV, PF>0.95

- *Clamps Stainless steel mounting clamps + Suspension provision

- *Life 50,000 Hours

- *Warranty 2 Years

*Why WPL 10 is Perfect for Utility Tunnels & Parking As Shown?*

*1. IP65 Dustproof ï As marked in image The tunnel in image has full dust from pipes and concrete. Normal batten will fill with dust inside in 3 months and light will drop 50%. WPL 10 is fully sealed with rubber gasket ï no dust enters ï light stays same for years.

*2. Polycarbonate Body ï Unbreakable As marked ï full PC body, not aluminium. No rust even in humid tunnel with water pipes. Can withstand 1m drop, vibration from heavy machines ï ideal for industries in Tirupur.

*3. 120 Wide Beam ï One Light Covers Full Width The image shows one WPL 40W covers full 8 ft width of tunnel ï both pipe side and floor. No dark patches. For a 100 meter long tunnel like in image, you need only one light every 10-12 ft ï saves cost.

*4. 2ft & 4ft ï Same Brightness 20W 2ft for short passages and corners, 40W 4ft for long runs ï same design family. Contractor can use mix in same site and look remains uniform.

*Applications*

- *Primary ï Utility Tunnels, Service Corridors, Pipe Galleries* ï As in main image

- Underground Car Parking, Basement Parking ï IP65 for water wash

- Factories, Knitting Units, Dyeing Units, Washing Units ï Dust + humidity

- Cold Storages, Dairy Plants, Food Processing ï Waterproof

- Poultry Farms, Dairy Farms, Car Washing Centers

- Staircase, Balcony, Outdoor Passage ï Where rain comes

*Installation Tip for Tunnel Like in Image*

For a tunnel 100 ft long x 8 ft wide as in image: Use 10 nos WPL 10 ï 40W 6000K, spacing 10 ft on one side wall at 8 ft height. Wiring with loop-in loop-out as WPL has both side waterproof glands as seen in top product image ï easy to connect.
