FINE LED Strip Lights ï 12V DC ï For Architectural Lines*

*Hotel Lobby Architectural Lines ï The Invisible Light That Makes Luxury Visible*

FINE LED Strip Lights are the secret behind the luxury hotel lobby in your image. All those glowing lines on ceiling cove, pillar edges, and reception base are NOT costly profile lights ï they are FINE 12V Strip Lights. They create continuous architectural lines without any dots or breaks, giving a 5-star luxury feel at low cost.

*Technical Specifications*

- *Model FINE LED Strip Light ï 12V DC ï 5 Meter Roll

- *LED Chip Options

- LED 2835 ï High brightness, high efficiency ï For long runs

- LED 5050 ï RGB & high power white ï For color changing

- COB LED ï Dot-free continuous line ï *Best for Hotel Lobby as in image*

- *Lighting Angle 120 Wide Beam ï Uniform wash, no dark edges

- *Voltage 12V DC ï Safe low voltage ï Needs external 12V driver

- *Available Colours as shown in bottom row

- 3000K Warm White ï Luxury gold ï *Used in main lobby ceiling cove in image*

- 4000K Neutral White ï Natural white

- 6000K Cool White ï Bright white

- RED, GREEN, BLUE, AMBER ï For festival, bar, DJ, signage

- *Roll Length 5 Meters ï Cuttable every 5cm ï Joinable

- *IP Options IP20 for indoor cove (as in image), IP65 waterproof on order for outdoor

- *Driver 12V DC SMPS ï 1A to 30A ï Separate ï 100V-285V AC input

- *Adhesive 3M self-adhesive tape at back ï Stick directly on POP, wood, aluminium profile

- *Life 30,000 Hours

- *Warranty 1 Year

*Why This is Ideal for Hotel Lobby Architectural Lines As Shown?*

The lobby image shows 4 places where strip lights are used:

1. *Ceiling Cove* ï Curved layered POP ï Warm 3000K strip gives floating ceiling effect

2. *Pillar Vertical Lines* ï Slim vertical lines on stone pillars ï Makes lobby look tall

3. *Reception Base* ï Under reception desk ï Floating effect

4. *Wall Recess Lines* ï Vertical lines beside gold panels

All this is done with low-cost 12V strip, not expensive linear profiles.

*3 Key Features as on Box

- *Affordable lighting and high quality performance One 5m roll costs less than 1 No aluminium profile light, but gives same luxury line effect. Brightness stays same for years, no color shift.

- *Range of fixed and variable color and brightness From warm 3000K to RGB ï one series for full project ïLobby 3000K, Bar BLUE, Festive RED/GREEN. Dimmable with dimmer.

- *Great addition to visual appeal The strip itself is invisible in day, only light line is visible at night ï architectural lighting at its best.

*Which Strip to Use Where in Lobby Image?*

- For *Ceiling Cove Use COB LED 3000K ï Dot-free continuous line as in top cove

- For *Pillar Vertical Use 2835 3000K in aluminium profile with diffuser ï Straight line

- For *Reception Use 2835 3000K IP20 ï Hidden base glow

*Applications*

- *Primary ï Hotel Lobby, Reception, Banquet* ï Architectural Lines as in image

- Homes ï False ceiling cove, Wardrobe, Kitchen under-cabinet, TV unit

- Shops & Showrooms ï Shelf edge, Counter edge

- Offices ï Ceiling design, Profile light making (buy LED strip + aluminium profile)

- Bar, Pub, Spa ï RED, BLUE, GREEN, AMBER mood lighting

*Installation Tip*

For a lobby like in image (ceiling perimeter 100 ft): Need 4 rolls of 5m (20m) COB 3000K + 1 No 12V 10A SMPS. Stick strip inside cove, connect parallel to driver. Always use aluminium channel for heat and straight line.

*Package Includes 1 x 5 Meter Roll + FINE Box (Driver sold separately)
