LED junction box lights JBL30

Name: LED junction box lights JBL30
Brand: FINETECH SYSTEMS
Price: 175.0 INR
Availability: InStock

Price 175.0 INR/ Piece

Get a Price/Quote

MOQ : 100 pieces Pieces

LED junction box lights JBL30 Specification

Operating Temperature
-10C to 45C

Power Supply
Integrated Driver

Response Time
<1 second

Efficiency (%)
>85%

Life Span
30,000+ hours

Humidity %
95% RH

Control Type
On/Off Switch

Beam
120

Housing
UV Stabilized Polycarbonate

Shape
Round

Current Rating
0.03A (max)

Light Color
Warm White / Cool White / Neutral White

Product Type
LED Junction Box Light

Material
Polycarbonate/Acrylic Housing

Base
Junction Box Mount

Power Factor
>0.90

Input Voltage
AC 90-265V, 50/60Hz

Working Temperature
-10C to 45C

Lamp Power
6W

Application
Indoor Lighting, Residential, Commercial Spaces

Size
3 Inch (approx.)

Dimension (L*W*H)
110mm x 110mm x 50mm (approx.)

Weight
95g (approx.)

Color
White

LED Type
Surface Mounted Device (SMD)

Color Temperature
3000K/4000K/6500K

IP Rating
IP20

Mounting
Surface Mount

Flicker-Free
Yes

Surge Protection
2.5kV

CRI (Color Rendering Index)
>80

Dimmable
No

Driver Type
Isolated Driver

LED junction box lights JBL30 Trade Information

Minimum Order Quantity
100 pieces Pieces

Delivery Time
1 Days

LED junction box lights JBL30 About

FINE JBL 30 Series LED Junction Box Lights 3W, 5W & 7W*

*One Light, 7 Colors, Infinite Interiors Fits Every Kitchen & Every Mood*

FINE JBL 30 Series is our most versatile junction box downlight range. As shown in the premium modular kitchen image, it sits flush in the ceiling and gives soft, even, 120 flood light perfect for kitchen, living room, bedroom. Available in 3 power options and 7 colors, it's the first choice for interior designers and electricians in Tamil Nadu.

*Technical Specifications*

- *Model JBL 30 Series LED Junction Box Light

- *Power Options

- 3W For accent / cove / showcase 330 Lumens

- 5W For kitchen / bedroom 550 Lumens

- 7W For living / large kitchen 770 Lumens

- *Beam Angle 120 Wide Flood Beam Shadow Free

- *Efficacy 110 Lumen/Watt High Brightness

- *Body Polycarbonate + Aluminum Heatsink, White Trim, FINE Branding

- *Diffuser Milky Opal, Anti-Glare

- *Cut-Out 75mm (3") for 3W & 5W, 90mm (4") for 7W

- *Driver Built-in, 100V-285V AC, PF>0.9, Surge 2.5kV

- *Life 50,000 Hours

- *Warranty 2 Years

*Available LED Colors 7 Colors as Shown*

Color | Kelvin | Best Use

3000K Warm White | Warm Yellow | Bedroom, Villa, Luxury Ceiling Cozy feeling

4000K Neutral White | Natural White | Kitchen, Study, Office As in top image, true color

6000K Cool White | Bright White | Shop, Showroom, Office, Bathroom Maximum brightness

Red / Green / Blue / Pink | Decor Colors | Festival lighting, Kids room, Bar counter, Temple, Feature wall

All colors glow exactly as shown in your "AVAILABLE COLORS" strip uniform without dots.

*Why JBL 30 is Dealers' No.1 Choice?*

*1. 3 Wattages in Same Design Stock only one design. Use 3W for shelf/wardrobe, 5W for kitchen corridor, 7W for hall. Same 120 beam, same fitting no confusion for electrician.

*2. 120 Wide Flood As Seen in Kitchen Image Top kitchen image shows 8 lights covering full L-shaped kitchen evenly. No dark patch on countertop. Better than 60 spot lights which create circles.

*3. Fits in Existing Junction Box No POP cutting cost. Remove old bulb holder in concrete slab, push JBL 30 with spring clips. 30-second installation. Ideal for renovation houses.

*4. 7 Colors in One Series From warm white for home to Red/Blue/Green/Pink for decoration one series covers full project requirement. Contractor doesn't need to search multiple brands.

*5. Glare Free & Cool Even after 10 hours in kitchen, body stays cool. Opal diffuser protects eyes important for ladies working long in kitchen.

*Recommended Application*

- *Kitchen & Modular Kitchen* As in main image Use 5W / 7W 4000K

- Living Room, Bedroom False Ceiling Use 5W 3000K

- Wardrobe Top, Showcase, Niche Use 3W 3000K

- Kids Room, Home Theatre, Hotel Use Red/Blue/Pink for mood

- Shops, Clinics, Offices Use 6000K 7W for brightness

*Installation Tip*

For a 12x14 ft modular kitchen like image: Use 6-8 nos of 5W, 4000K Neutral White, spacing 3 ft. For living room: Use 3000K warm for luxury hotel feel.

Superior Light Quality and Efficiency

The JBL30 LED junction box light boasts a CRI greater than 80, ensuring colors are rendered vividly and naturally in any indoor setting. With its exceptional efficiency rating exceeding 85%, it delivers bright, clear light while maintaining lower energy consumption. This fixture is ideal for locations that demand accurate color representation and consistent performance.

Robust Construction and Safe Operation

Built with UV-stabilized polycarbonate housing, the JBL30 not only resists discoloration but also stands up to challenging indoor environments, including high humidity levels up to 95% RH. The integrated isolated driver, coupled with 2.5kV surge protection, safeguards against power fluctuations, offering you peace of mind in both residential and commercial installations.

FAQ's of LED junction box lights JBL30:

Q: How is the JBL30 LED junction box light installed?

A: The JBL30 is designed for surface mount installation onto standard junction boxes. Its compact round shape (3 inches) and lightweight build make the setup straightforward, requiring only basic tools and standard wiring knowledge.

Q: What type of applications is the JBL30 best suited for?

A: This LED light is ideal for a range of indoor applications, including residential rooms, hallways, and commercial spaces like offices and shops. It provides reliable, flicker-free illumination suitable for environments where consistent and efficient lighting is essential.

Q: When should I choose the JBL30 over other lighting options?

A: Opt for the JBL30 when you need a durable, energy-efficient, and long-lasting fixture that offers a high CRI, multiple color temperature options (warm, neutral, or cool white), and protection from electrical surges. Its flicker-free operation makes it especially valuable for areas where visual comfort is a priority.

Q: Where can this light be used given its IP20 rating?

A: The JBL30 LED light is suitable solely for dry, indoor locations due to its IP20 rating. It should not be used in areas exposed to water or excessive moisture, such as bathrooms or outdoor environments.

Q: What are the benefits of the JBL30's flicker-free and isolated driver design?

A: The flicker-free performance ensures visual comfort, reducing eye strain and creating a pleasant lighting environment. The integrated isolated driver enhances product safety and stability by minimizing electrical interference and supporting a lifespan of over 30,000 hours.

Q: Is the JBL30 dimmable, and how is it controlled?

A: No, the JBL30 is not dimmable. Its operation is managed via a simple on/off switch, providing instant full illumination with a response time of less than one second.
