LED surface panel lights

LED surface panel lights About

FINE SPL 10 Series ï LED Surface Panel Lights ï 6W, 12W & 18W*

*Sleek. Efficient. Brilliant. ï The Retail Display Light*

FINE SPL 10 Series is a premium rimless surface panel light designed for boutiques, showrooms, and shops that have NO false ceiling. As shown in the luxury fashion boutique image, both Square and Round surface panels are fixed directly on the concrete ceiling and give bright, uniform light that makes every product shine ï handbags, shoes, and new collection dresses look premium and true-to-color.

*Tagline for Poster: BRIGHT LIGHTING. BEAUTIFUL DISPLAYS.*

*Technical Specifications*

- *Model SPL 10 Series ï LED Surface Panel Light

- *Power Options

- 6W ï 660 Lumens ï For trial room, small cabin, shelf focus

- 12W ï 1320 Lumens ï For billing area, display table

- 18W ï 1980 Lumens ï For main showroom area as in image ï Best Seller

- *Shapes

- Square ï Modern boutique look (as seen on top ceiling in image)

- Round ï Soft elegant look (as seen in middle ceiling in image)

- Both shapes available in same wattage

- *LED Colors

- Cool White 6000K ï Maximum brightness for commercial

- Neutral White 4000K ï True color for clothes ï *Most selling for textile as in image*

- Warm White 3000K ï Luxury warm for premium brands

- *Body White Polycarbonate ï Ultra Slim 32mm ï Rimless design

- *Diffuser High transmission PS diffuser ï No dots, UGR<19

- *Driver Built-in High PF Driver, 100V-285V AC, Surge 2.5kV, PF>0.9

- *Mounting Surface Mount ï 2 screws ï No cutting, No POP needed

- *Life 50,000 Hours

- *Warranty 2 Years

*Why SPL 10 is Perfect for Retail Showrooms As Shown?*

*1. Make Every Product Shine The boutique image proves it ï 18W panels give high brightness that highlights texture of bags, leather shoes, and fabric. 4000K Neutral White shows exact color of dress to customer ï no returns due to color mismatch.

*2. Sleek Surface ï No False Ceiling As in image, lights are directly on slab. Saves Rs.80-100 per sq.ft false ceiling cost. Ideal for rented shops and quick renovations. Install in 5 minutes.

*3. Square & Round ï Mix & Match Use Square for main area (modern look) and Round for trial rooms and corridors ï as done in image. Both shapes in same family gives designer uniformity.

*4. 5 Benefits as per Bottom Strip

- *High Brightness Uniform Light 110 Lm/W, full area covered, no dark patches on display tables

- *Energy Efficient Low Power 18W replaces 2x18W CFL surface ï saves 50% bill

- *Flicker Free Eye Comfort No flicker on camera ï good for Instagram reels of boutique, staff eye comfort for 12 hour duty

- *Easy Installation Surface Mount No need for electrician to cut ceiling ï just screw

- *Long Life Reliable Performance BIS approved driver, no early failure ï important for shops where daily sales depend on light

*Applications*

- *Primary ï Fashion Boutiques, Textile Showrooms, Garment Shops* ï As in image ï NEW COLLECTION area

- Handbag & Footwear Showrooms ï Shelf focus

- Jewellery Showrooms ï Billing & Trial Area

- Offices without False Ceiling, Clinics, Pharmacies

- Homes ï Kitchen, Bedroom, Living where POP cutting not possible

*Installation Tip for Boutique Like in Image*

For a shop 20x15 ft as in image: Use 4 nos 18W SPL 10 ï 2 Square + 2 Round, 4000K Neutral White, spacing 8 ft. For display shelves with bags/shoes, add 1 No 6W SPL above shelf for extra focus.
