LED slim back panel lights

Price 2800.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

LED slim back panel lights Trade Information

Minimum Order Quantity
1 Number

Delivery Time
2 Days

LED slim back panel lights About

FINE SBPL 10 Series LED Slim Back Panel Lights 2x2 Feet 36W & 48W*

*The Mall Lighting Specialist Slim, Bright, Uniform*

FINE SBPL 10 Series is a super slim 2x2 feet back-lit LED panel, designed specifically for shopping malls, showrooms, and large commercial spaces where you need high brightness with zero dark patches. As shown in the mall image, 2x2 panels fitted in continuous rows give clean, premium, daylight-like illumination that makes brands like Lifestyle, Westside, Max, TRENDS look more attractive and increases customer shopping time.

#### *Technical Specifications*

- *Model*: SBPL 10 Series Slim Back Panel Light 2x2 Feet

- *Power Options*:

- 36W 3960 Lumens For 10 ft height Shops, Offices

- 48W 5280 Lumens For 12-15 ft height Malls, Atrium, Big Showrooms (Best for Malls)

- *LED Colors*:

- Cool White 6000K Maximum brightness For Mall corridors as in image

- Neutral White 4000K Soft white for premium brands

- Warm White 3000K Luxury warm for hotel lobbies & reception

- *Shape*: Square 595x595mm Standard 2x2 feet Fits Armstrong ceiling directly

- *Technology*: Back-lit Panel Edge-to-edge brightness, No yellowing in center

- *Efficacy*: 110 Lumen/Watt

- *Body*: Aluminum Frame + Back Cover, White Finish, Ultra Slim 30mm

- *Diffuser*: High Transmission PS Diffuser UGR<19 Soft & Uniform Light, No Dots

- *Driver*: External High PF Isolated Driver, 100V-285V AC, Surge 4kV, PF>0.95

- *Life*: 50,000 Hours

- *Warranty*: 2 Years

#### *Why SBPL 10 is Ideal for Malls as Shown?*

*1. SLIM DESIGN SLEEK & MODERN*: The product image shows just 30mm slim thickness. Looks flush with false ceiling, gives high-end international mall look. Light weight doesn't load ceiling.

*2. SOFT & UNIFORM LIGHT OUTPUT*: Back-lit technology spreads light evenly across full panel. Unlike old front-lit panels that get yellow in middle after 6 months, SBPL stays uniform for years. As in top mall image, no flicker, no dark lines between panels.

*3. ENERGY EFFICIENT, LONG LIFE*: 48W SBPL replaces old 4x14W T5 (72W) or 2x36W CFL (86W) fixtures. Saves >50% EB bill. Runs cool reduces AC load in mall. 50,000 hours = 6 years at 12 hours daily.

*4. PREMIUM QUALITY SUPERIOR*: FINE branded driver with 4kV surge protection important for commercial EB with fluctuations. No early failures critical for malls where changing lights at height is costly.

*5. Perfect for High Ceilings*: 48W variant is made for 12-15 ft mall corridors as in image. High lumen maintains lux at floor level for safety and product visibility.

*Applications*

- *Primary Shopping Malls* As in image Mall Atrium, Corridors, Walkways

- Large Branded Showrooms Lifestyle, Trends, Westside Type

- Corporate Offices, IT Parks, Conference Halls

- Hospitals, Educational Institutions, Banks

- Textile & Jewellery Showrooms with 2x2 Grid Ceiling

*Installation Tip for Malls*

For mall corridor like in image (width 20-30 ft, height 14 ft): Use 48W 6000K Cool White with 8 ft x 8 ft spacing in 2 rows. For inside shops, use 36W 4000K for true color of dresses.
