LED junction box lights

LED junction box lights About

FINE JBL 20 Series LED Junction Box Light 6W 120 Wide Beam*

*Work Smarter Under Perfect Light*

FINE JBL 20 Series is a premium recessed downlight designed for home office, study room, and work desks where you need bright, uniform, eye-friendly light. As shown in the image, one 6W light with 120 wide beam covers the entire work table no dark corners, no eye strain.

Unlike normal small junction box lights, JBL 20 has a deeper heatsink and wider trim for better cooling and superior light spread.

#### *Technical Specifications*

- *Model*: JBL 20 Series LED Junction Box Light

- *Wattage*: 6W

- *Beam Angle*: 120 Wide Beam Flood Light

- *Lumen Output*: 110 Lm/W 660 Lumens

- *Color Temperature*: Neutral White 4000K (As in image) Best for Work

- *Other Colors Available*: 3000K Warm White, 6000K Cool White on order

- *Body*: Die-cast Aluminum Heatsink + Polycarbonate Trim White

- *Diffuser*: High-Transmission Opal PC Glare Free

- *Driver*: Built-in Constant Current, Wide Voltage 100V-285V AC, PF >0.9

- *Cut-out*: 75mm Fits Standard 3-Inch Junction Box & False Ceiling

- *Life*: 50,000 Hours

- *Warranty*: 2 Years

#### *Why JBL 20 Series for Office & Study?*

*1. 4000K Neutral White The Focus Light*: The image shows "FOCUS PLAN EXECUTE SUCCEED". 4000K is scientifically proven to improve concentration. Not yellow like 3000K (makes you sleepy), not harsh like 6000K. Ideal for WFH table, study table, office cabin as shown.

*2. 120 Wide Beam One Light Covers Full Table*: As illustrated with dotted lines in poster, light spreads wide. A 10x10 ft home office needs only 2-3 lights vs 4-6 spot lights. Saves power and wiring.

*3. Premium Aluminum Heatsink Design*: The image shows the deep fin-type heatsink at bottom. Dissipates heat quickly, maintains brightness for years. No yellowing, no flickering.

*4. Direct Fit in Junction Box & POP*: Fits in existing 3-inch round box in slab or in false ceiling. No need for big 4-inch cutting. Spring clip locking 30 second installation.

*5. Glare Free Eye Comfort for Long Hours*: Opal diffuser + recessed LED plate ensures soft light on laptop screen and books. No reflection on eyes during 8-hour work.

#### *Ideal Applications*

- *Primary Application*: Home Office, Study Room, Office Cabin (As shown in image)

- WFH Desk, Computer Table

- Bedroom, Living Room For regular slab roof

- Library, Reading Area, Conference Table

- Retail Counters, Lab, Clinic

#### *Installation Tip for Office*

For a 120 sq.ft home office as in image, install 1x 6W at center of table + 2 more at room corners at 5-6 ft spacing. Use 4000K Neutral White for best productivity. Height 9-10 ft is ideal for 120 spread.
